Description
Nano-Ceramic Series, for all uses (Residential, commercial and automotive), unlike traditional films, its high technology at the molecular level provides the greatest rejection of solar energy without darkening the glass and without metal content.
It is currently the best mechanism to drastically reduce the heat caused by solar energy that passes through the crystals.
THE BEST QUALITY
Properties
The best rejection and heat reduction
They filter 99% of UV rays
Maximize air conditioning efficiency
Protects furniture from deterioration and discoloration
It reduces energy consumption
Specs
| PRODUCT CODE | PLY | VLT | IR REJECT | INT. REFLEC. | EXT. REFLEC. | TOTAL SOLAR ENER. REJ. | SOLAR HEAT GAIN COEF. |
|---|---|---|---|---|---|---|---|
| IR-7090 | 1.5 mil | 73 % | 90 % | 4.5 % | 3.8 % | 61 % | 0.43 |
| IR-5090 | 1.5 mil | 51 % | 94 % | 5.0 % | 5.0 % | 75 % | 0.34 |
| IR-3090 | 1.5 mil | 33 % | 91 % | 5.0 % | 5.0 % | 79 % | 0.34 |
| IR-8080 | 1.5 mil | 80 % | 80 % | 4.7 % | 3.8 % | 52 % | 0.50 |
| IR-7070 | 1.5 mil | 80 % | 62 % | 4.5 % | 3.8 % | 51 % | 0.54 |
| IR-3070 | 1.5 mil | 32 % | 77 % | 5.0 % | 5.0 % | 71 % | 0.43 |
